Overview
Elevate your events with the Shizhan Professional Aluminum Truss System. Engineered for strength, versatility, and rapid deployment, our modular truss is the reliable backbone for demanding stage, audio, and lighting setups worldwide. Crafted from high-grade aluminum alloy and featuring a robust quick-install design, it's the go-to solution for both indoor and outdoor productions.
Key Features & Benefits
Unmatched Strength: Supports heavy loads up to 1000 kg.
Ultra-Fast Assembly: Quick-install connectors for rapid setup and teardown.
Modular Flexibility: Modular structure allows infinite configurations to fit any space or design (straight, arch, curve roof, ladder truss).
Premium Material: Constructed from high-strength Aluminum Alloy 6082-T6.
Lightweight & Portable: Significantly lighter than steel, yet incredibly strong. Foldable and easy to transport.
Built to Last: Engineered for heavy-duty use, durable, and weather-resistant for outdoor reliability.
Versatile Shapes: Available in Square, Triangle, Circle (Round), Rectangle, Arch, Curve Roof, and Ladder Truss profiles.
Secure Connections: Options include Screw Connection, Pin Connection, Welded Connection, and Quick Connection (Quick-Lock System).
Frame Design: Square cross-section with Assembly Armor reinforcement.
Technical Specifications
| Attribute | Specification |
| Product Type | Stage Truss, Line Array Speaker Truss Stand Tower |
| Model | Aluminum Truss |
| Material | Aluminum Alloy 6082-T6 |
| Main Tube | 50mm x 3mm (Diameter/Wall Thickness) |
| Hardness | 16 degrees |
| Load Capacity | 1000 kg |
| Structure Type | Modular |
| Assembly Method | Quick Installation |
| Cross-Sections | 200x200mm, 290x290mm, 350x350mm, 400x400mm (Standard Sizes) |
| Unit Lengths | 0.5m, 1m, 2m, 3m, 4m, 5m (Standard Lengths) |
| Height | Customizable |
| Width/Length | Customizable (Beyond standard sizes) |
| Color | Standard: Silver, Black. Fully Customizable to your requirements. |
| Finish | Anodized or Powder Coated (for durability & corrosion resistance) |
| Origin | Jiangsu, China |
Applications
Ideal for a wide range of events and installations:
Concerts & Music Festivals (Outdoor/Indoor)
Corporate Events & Conferences
Trade Shows & Exhibitions
Theatrical Productions & Stage Setups
DJ Booths & Lighting Rigs
Permanent Installations (Venues, Clubs, Houses of Worship)
Outdoor Events & Festivals
Advantages
Portable: Easy to transport and handle.
Durable: Built to withstand rigorous use and environmental conditions.
Foldable: Optimizes storage space.
Lightweight: Reduces shipping costs and labor.
Quick Installation: Saves valuable setup time.
Assembly Armor: Enhances structural integrity and connection security.
Certifications
Our manufacturing processes and materials meet the highest international standards, verified by:
CE • SGS • TÜV (Mark R 50446290) • ISO 9001 • RoHS
Packaging & Shipping
Sales Unit: Single Item
Package Dimensions (Per Unit): 100 cm x 29 cm x 29 cm
Gross Weight (Per Unit): 9.000 KG
Lead Time: Please contact us for details based on order size and customization.
Customization Options (MOQ Applies)
Make the Shizhan Truss uniquely yours:
Customized Logo: (Minimum Order Quantity: 50 meters)
Customized Packaging: (Minimum Order Quantity: 100 meters)
Custom Graphics/Finishes: (Minimum Order Quantity: 100 meters)
Custom Sizes & Shapes: Bespoke dimensions and configurations available.
Custom Colors: Any RAL or Pantone color upon request.
Why Choose Shizhan Truss?
Shizhan combines robust engineering with practical design, delivering truss systems that professionals trust for critical event infrastructure. Our commitment to quality, backed by international certifications, ensures you get a reliable, safe, and high-performance product every time.
Ready to build something amazing? Contact us today for a quote or to discuss your specific project requirements!
