High quality customizable aluminum DJ lighting truss faucet truss portable aluminum alloy truss display
- Overview
- Recommended Products
Overview
Premium 6082-T6 aluminum truss system with multiple connection options and configurations. Features 500kg load capacity, quick assembly design, and extensive customization. Ideal for DJ setups, concerts, and exhibitions.
Key Features & Benefits
Heavy-Duty Structure: 500kg load capacity per section
Quick Assembly: Multiple connection options (quick/pin/screw)
Assembly Armor™ Design: Reinforced joint technology
Full Customization: Colors, lengths, and configurations
All-Weather Use: Anodized aluminum corrosion resistance
Versatile Shapes: Square, circle, triangle, arch, and custom designs
Portable Design: Lightweight yet incredibly strong
Technical Specifications
| Category | Specifications |
| Model | Aluminum Truss |
| Material | 6082-T6 Aluminum Alloy |
| Main Tube | 50mm x3mm thickness |
| Standard Sections | 200x200mm·290x290mm·350x350mm·400x400mm |
| Unit Lengths | 0.5m·1m·2m·3m·4m·5m·Custom lengths |
| Connection Types | Quick Connect·Pin Connect·Screw Connect |
| Load Capacity | 500kg per section |
| Hardness | 16 degrees |
| Color Options | Silver·Black·White·Orange·Yellow·Green·Blue·Custom colors |
| Shape Options | Square·Circle·Triangle·Rectangle·Arch·Curve Roof·Ladder Truss |
| Certifications | CE·SGS·TUV·ISO 9001·RoHS |
Configuration Options
DJ Truss Setups: Booth framing • Overhead lighting
Concert Systems: Speaker towers • Lighting rigs
Exhibition Structures: Booth frames • Signage support
Custom Designs: Arches • Circles • Specialty shapes
Applications
Entertainment: Concerts • Clubs • DJ performances
Events: Weddings • Conferences • Exhibitions
Corporate: Product launches • Brand experiences
Outdoor: Festivals • Temporary installations
Retail: Display systems • Pop-up installations
Packaging & Shipping
Detail: Specification
Sales Unit: Per Meter
Package Dimensions: 100 × 29 × 29 cm
Gross Weight: 9 kg/meter
Lead Time: 1-100m: 3 days • 101-300m: 5 days • 301-500m: 7 days • 500m+: Custom
Global Shipping: Air & sea freight optimized
Customization Services
Logo Printing (MOQ: 50 meters)
Custom Packaging (MOQ: 100 meters)
Graphics & Branding (MOQ: 100 meters)
Special Powder Coating (Any RAL color)
Bespoke Dimensions & Shapes
Integrated Cable Management
Certifications & Quality
[CE] [SGS] [TÜV] [ISO9001] [RoHS]
Full compliance with international safety standards
Complete System Includes
Main truss sections
Connection hardware
Safety certification
Assembly manual
Custom branding (if selected)
